12mm Square Shoulder Indexable End Mill APMT1135PDER Carbide Inser 1Flute
- Cutter diameter is 12mm / 0.472″.
- Shank diameter is 12mm / 0.472″.
- 1 flute.
- Flute length is 30mm / 1.182″.
- Overall length is 120mm / 4.724″.
- Torx wrench is a T8 #2100-0092.
- Screw M2.5 x 6
- Insert NOT INCLUDED
- Shipping Weight: 0.2 lbs
The Shop Tool USA 12mm Square Shoulder Indexable End Mill with APMT1135PDER Carbide Insert and 1 Flute is a high-performance cutting tool designed for precision machining applications. This versatile end mill is manufactured to deliver exceptional cutting performance and efficiency in various materials.
Key Features:
- Square Shoulder Design: The 12mm Square Shoulder Indexable End Mill features a square shoulder design that provides enhanced stability and rigidity during machining operations. This design ensures accurate and reliable cutting results, minimizing vibration and chatter.
- APMT1135PDER Carbide Insert: The end mill is equipped with an APMT1135PDER carbide insert, renowned for its excellent wear resistance and durability. This high-quality insert ensures long tool life, reducing the need for frequent replacements and enhancing cost-effectiveness.
- 1 Flute Configuration: The single flute configuration of this end mill allows for efficient chip evacuation, preventing chip buildup and improving cutting performance. The optimized flute geometry enables smooth and precise cutting, resulting in high-quality surface finishes.
- Indexable Design: The indexable feature of this end mill allows for easy insert replacement, reducing downtime and enhancing productivity. The inserts can be rotated or replaced individually, providing flexibility and cost savings compared to solid carbide end mills.
- Versatile Applications: The Shop Tool USA 12mm Square Shoulder Indexable End Mill is suitable for a wide range of machining applications, including face milling, slotting, profiling, and ramping. It can effectively machine materials such as steel, stainless steel, cast iron, and non-ferrous metals.
- Precision and Accuracy: This end mill is designed to deliver precise and accurate machining results. The combination of its high-quality carbide insert, rigid construction, and optimized cutting geometry ensures consistent performance and dimensional accuracy.
- Compatibility: The 12mm Square Shoulder Indexable End Mill is compatible with standard milling machines and CNC machining centers. It can be easily integrated into existing machining setups, making it a convenient tool for various manufacturing environments.
