KTM-3VKF CNC w/ MillPwr
3 HP spindle motor with AC-Frequency drive, digital RPM display, load meter
and automatic spindle direction reversal when switching between high and low speed gear ranges.
Can run on either single phase or 3 phase power
10” x 50” (Opt. 10″ x 54″) hardened and ground table top Table, saddle, and knee with hardened and ground dovetail ways
Precision ground leadscrews with backlash compensating double nut
Precision bored and ground milling head, with super precision ABEC-7 bearings
Meehanite castings, with built in coolant reservoir in machine base
Centralized one-shot lubrication, with metered check-valves
Easy conversational programming, DRO-mode allows for full manual operations with built-in 3 axis absolute encoder glass scales
Engraving feature and DXF file import capability, USB drive and 12.1” high resolution flat panel color LCD display
Table Size | 50” x 10” (54” x 10” optional) |
Table Travel | 36” (32” w/ cnc control) |
Saddle Travel | 15.25” (14” w/ cnc control) |
Knee Travel | 15” |
Ram Travel | 22” |
Quill Travel | 5” (4” w/ cnc control) |
Quill Diameter | 3.375” |
Spindle Motor | 3HP (inverter-duty) |
Spindle Taper | R-8 (NMTB-30 or Quick change spindle optional) |
Spindle Speeds | 60–550–4500 rpm (60–6000* on HS head optional) |
Overall Width | 102” |
Overall Depth | 79” |
Overall Height | 90” |
Table to Floor | 34” – 49” |
Spindle to Table | 2.75” – 17.75” |
Spindle to Column | 5” – 27” |
Maximum Workload | 850 lbs (centered) |
Shipping Dimension | 72” x 72” skid |
Shipping Weight | 3,300 LBS |
Net Weight (approx) | 3,100 LBS |
User-Friendly Save Valuable Time
Standardized menus make it easy to program
common features; simply press any function key
and follow the prompts. Use MILLPWRG2 for
arcs, blends and circles in any size, shape or
pattern your print requires. There is no need to
set up rotary tables or other devices.
MILLPWRG2 also includes an engrave function
for engraving alphanumeric characters vertically,
horizontally, diagonally or along an arc.
Save time with the skew feature, which enables
the user to set up a workpiece without perfectly
aligning it along the X and Y-axes. MILLPWRG2 will
compensate for the angle offset from start to finish.
The teach position feature allows the operator to use a tool,
electronic Edge Finder or indicator to create a program
from an existing part.
