PENTA24N200J020 IC908 Carbide Insert 5pc Pack

$298.50

U.S. Ground Delivery 3 -7 Days

International Order 12 – 15 Days



PENTA24N200J020 IC908 Carbide Insert 5pc Pack

Parting and precision grooving insert on soft parts, minimizes burr size. Most economical system with 5 cutting edges.

Cutting Width (CW) 0.079″ Application | Ext. Grooving | Ext. Grooving & Turning | Groove Turn & Parting Inserts | Parting |
Corner Radius (RE) 0.0079″ Applicable Material | Steel | Stainless Steel | Cast Iron | Hard Materials | Hi Temp Alloys |
Corner Radius Tolerance (+/-) (RETOL) 0.0012″ Max. Grooving Feed (fg(max)) 0.0047 ″/rev
Cutting Depth Maximum (CDX) 0.236″ Min. Grooving Feed (fg(min)) 0.0016 ″/rev
Cutting Edge Material Carbide Chip Breaker Type J
Coating TiAlN Series/List # PENTA24N200J020
Grade IC908 Tool Type Parting & Grooving Inserts
Shape 108° Pentagonal Measurement Type Inch
Cutting Direction (HAND) Neutral Body Material Carbide
PENTA 24N200J020 IC908
Weight 1 lbs
