VERTEX M8 X 1.25 SCREWDRIVER TYPE BALL PLUNGER (8017-0104)

VERTEX M8 X 1.25 SCREWDRIVER TYPE BALL PLUNGER (8017-0104) (SKU: 8017-0104)

M8 X 1.25 Screwdriver Type Ball Plunger

• Body Material: 12L14 Steel
• Ball Material: 302 Stainless Steel
• Smallest and lightest spring loaded device
• Side-load tolerant
• Controlled end forces
• Screwdriver installation
• Ball diameter is 5.0mm
• L Dimension is 15mm
• Initial end force is 7 lbs
• Final force is 19 lbs

Specifications

• M8 X 1.25 Screwdriver Type Ball Plunger
• Body Material: 12L14 Steel
• Ball Material: 302 Stainless Steel
• Smallest and lightest spring loaded device.
• Side-load tolerant.
• Controlled end forces.
• Screwdriver installation.
• Ball diameter is 5.0mm. ~ ~ ~
• L Dimension is 15mm.
• Initial end force is 7 lbs.
• Final force is 19 lbs.
• Vertex # VBP-08I
• Weight: 0.01
• Dimensions: L 3, W 1, H 6

Benefits

• Industrial-grade tooling designed for dependable shop performance.
• Supports consistent results when applied with correct setup practices.
• A practical choice for U.S. machine shops and maintenance work.

Recommended use

• Confirm compatibility (size, interface, machine capacity) before ordering.
• Follow safe operating practices and use appropriate PPE.
• Optimize setup rigidity and process parameters for best results.

USA Warehouse Stock — Fast U.S. fulfillment.
