10″ 3 jaw Self Centering Lathe Chuck GATOR Cast-Iron Body 2pc Hard Reversible Jaw

Original price was: $861.00.Current price is: $688.00.

GATOR Lathe Chuck Semi Steel Scroll

Delivery 3-5 days

Fulfillment by manufacturer



SKU: 1-201-1000 Category:

10″ 3 jaw Self Centering Lathe Chuck GATOR Cast-Iron Body 2pc Hard Reversible Jaw

Product Information

Chuck TypeScroll Self-Centering
Chuck MountPlain Back
Spindle TypeRequires Adapter
Chuck Dia (in)10
Thru-Hole (in)2.9921
Gripping Range Min-Max (in)0.20 – 9.84
Chuck T.I.R (in)0.0016
Max RPM2000
MaterialCast Iron
Jaws3
Jaw Type2 PC Hard  Reversible
Weight Gross (lbs)57.76
Includes1 Set of Master and Hard Top Reversible Jaws, Adapter Mounting Bolts, Chuck Wrench, Hex Keys, Eye Bolts

roduct Dimensions

D (in)10
F  (in)8.8189
E (H7) (in)7.8740
d Hole (in)2.9921
C (in).1969
H  (in)3.347
h  (in)2.1457
M Mounting Bolt ThreadM12x1.75
M Mounting Bolt Length
(in)
1.18
Mounting Bolt
Qty
6

Crossover to Other Brands

Bison7-800-1000
Spare Parts
Chuck Wrench (1 pc)W-P-200
Scroll (1 pc)SC-PS-200
Pinion (1 pc)PI-PS-200
Pinion Screw (1 pc)PH-P-200
Chuck Mounting Bolts (1 pc)MB-BS-200
Spare Parts
Chuck Wrench (1 pc)W-P-315
Scroll (1 pc)SC-PS-250
Pinion (1 pc)PI-PS-250
Pinion Screw (1 pc)PH-P-250
Chuck Mounting Bolts (1 pc)MB-BS-250
Weight33.51 lbs
