End Mill Set 3/16-3/4 HSS 4 Flute Single End Uncoated
Description:
- Right hand (clockwise rotation) cutting direction
- Center cutting design with good chip removal capability
- Ground from high grade solid HSS blank
- Ideal for general purpose plunge, pocket and profile milling
| DIAMETER | SHANK | LENGTH OF CUT | OAL | NUMBER OF FLUTES |
|---|---|---|---|---|
| 3/16 | 3/8 | 1/2 | 2-3/8 | 4 |
| 1/4 | 3/8 | 5/8 | 2-7/16 | 4 |
| 5/16 | 3/8 | 3/4 | 2-1/2 | 4 |
| 3/8 | 3/8 | 3/4 | 2-1/2 | 4 |
| 7/16 | 3/8 | 1 | 2-11/16 | 4 |
| 1/2 | 1/2 | 1-1/4 | 3-1/4 | 4 |
| 9/16 | 1/2 | 1-3/8 | 3-3/8 | 4 |
| 5/8 | 5/8 | 1-5/8 | 3-3/4 | 4 |
| 11/16 | 5/8 | 1-5/8 | 3-3/4 | 4 |
| 3/4 | 3/4 | 1-5/8 | 3-7/8 | 4 |
