HARLINGEN MT3 EXTENDED POINT HIGH SPEED CNC B-TYPE LIVE CENTER (9741-0233)

HARLINGEN MT3 EXTENDED POINT HIGH SPEED CNC B-TYPE LIVE CENTER (9741-0233) (SKU: 9741-0233)

Harlingen MT3 Precision High Speed CNC B-Type Live Center

• Especially suited for cramped work areas between center point and workpiece
• High concentricity and stability thanks to a high accuracy bearing system
• The tip has a 60 degree included angle
• The body is hardened for extra strength and rigidity
• Lifetime lubrication for minimum required maintenance
• Maximum concentricity deviation for ultra precision
• Point is made of high quality alloy steel that has been heat treated to hardness HRC62

Specifications

• Harlingen MT3 Precision High Speed CNC A-Type Live Center
• High concentricity and stability thanks to a high accuracy bearing system.
• The tip has a 60 degree included angle.
• The body is hardened for extra strength and rigidity.
• Lifetime lubrication for minimum required maintenance.
• Maximum concentricity deviation for ultra precision.
• Point is made of high quality alloy steel that has been heat treated to hardness HRC62.
• Especially suited for cramped work areas between center point and workpiece.
• Weight: 2.4
• Dimensions: L 8, W 4, H 4

Benefits

• Industrial-grade tooling designed for dependable shop performance.
• Supports consistent results when applied with correct setup practices.
• A practical choice for U.S. machine shops and maintenance work.

Recommended use

• Confirm compatibility (size, interface, machine capacity) before ordering.
• Follow safe operating practices and use appropriate PPE.
• Optimize setup rigidity and process parameters for best results.

USA Warehouse Stock — Fast U.S. fulfillment.
