PRO-SERIES PERMANENT MAGNETIC SINE BAR – MADE IN TAIWAN (3800-5410)

PRO-SERIES PERMANENT MAGNETIC SINE BAR – MADE IN TAIWAN (3800-5410) (SKU: 3800-5410)

Pro-Series Permanent Magnetic Sine Bar

• Made in Taiwan
• Overall length is 3″
• Designed for any machine on angular testing
• Magnetic base with permanent power pull of 8 lbs
• Hardened and precision ground HRC 56
• 68
• Parallelism within 0.0001″
• Squareness within 0.0002″
• Distance between roll centers is 2″
• Accuracy of rolls is +0.00008″

Specifications

• Pro-Series Permanent Magnetic Sine Bar
• Made in Taiwan.
• Overall length is 3″.
• Designed for any machine on angular testing.
• Magnetic base with permanent power pull of 8 lbs.
• Hardened and precision ground HRC 56~68.
• Parallelism within 0.0001″.
• Squareness within 0.0002″.
• Distance between roll centers is 2″.
• Accuracy of rolls is +0.00008″.
• Weight: 1
• Dimensions: L 3, W 1, H 6

Benefits

• Industrial-grade tooling designed for dependable shop performance.
• Supports consistent results when applied with correct setup practices.
• A practical choice for U.S. machine shops and maintenance work.

Recommended use

• Confirm compatibility (size, interface, machine capacity) before ordering.
• Follow safe operating practices and use appropriate PPE.
• Optimize setup rigidity and process parameters for best results.

USA Warehouse Stock — Fast U.S. fulfillment.
